Description

Big Squid White
Magnetic stirrer with glass surface and different motives
– Digital speed display (LED)
– Electronically controlled motor for more capacity
– Higher speed range from 0 – 2.500 rpm
– Max. stirring quantity 1,5 l
– Outstanding chemical resistance due to glass top and synthetic bottom made of TPC-ET
– Recyclable materials

Technical data :
– Power input : 4W
– DC Voltage : 12V=
– Frequency : 50/60Hz
– Voltage : 100 – 240V
– Permissible relative humidity : 80%
– Current consumption : 300mA
– Stirring quantity max. per stirring position (H2O) : 1.5l
– Weight : 0.7kg
– Depth : 205mm
– Width : 185mm
– Set-up plate dimensions : Ø 160mm
– Permissible ambient temperature max. : 40°C
– Permissible ambient temperature min. : 5°C
– Speed display set-value : LED
– Protection class according to DIN EN 60529 : IP 54
– Direction of rotation : right
– Speed control : Turning knob
– Set-up plate material : glass
– Motor rating output : 2W
– Speed max. : 2500rpm
– Height : 45mm
– Setting accuracy speed : 50rpm
– Stirring bar length max. : 30mm
– Speed min. : 0rpm
– Number of stirring positions : 1
