Description

ATE Magnetic Stirrer
High power magnetic stirrer suitable for medium-high volumes.

Proven Reliability
– Control panel is shielded from liquid spills
– Epoxy-coated tough steel casing
– Accepts up to 25 liter flask
– Designed for the longest lifespan and guaranteed by 3 years warranty

Applications in Mind
– High power for viscous liquids
– Pale surface for visualization of particles and color changes
– Soft start but rapidly reaching set speed

Simple & Practical
– Speed regulation up to 1200 rpm
– Choice of mains voltage / frequency model

GENERAL FEATURES :

Models:	– ATE, 230 V / 50-60 Hz, Cat. No. : F20300165 – ATE, 115 V / 50-60 Hz, Cat. No. : F20310165
Construction material:	epoxy painted metal structure
Power:	25 W
Weight:	3.7 Kg (8.1 lb)
Dimensions (WxHxD):	250x120x285 mm (9.8×4.7×11.2 in)
PERFORMANCE
Electronic speed regualtion:	up to 1200 rpm
Stirring volume (H2O):	up to 25 liters
Stirring system	high-power driving magnet type ”PCM” operated by a mono-phase motor for continuous operation
