Jual Overhead Stirrer Mixer MICROSTAR 7.5 control Ika

Description

MICROSTAR 7.5 control
Overhead Stirrers

The new MINISTAR series by IKA: Developed using the latest cutting-edge technology, this high-tech overhead stirrer with its compact design is ideal for special applications.
Combining high performance with particular excellence, they require minimum space and come with a lifetime guarantee.
– Hardened glass enclosed, fast response display for maximum visibility and chemical resistance
– State-of-art vibration sensors detect deviations from permissible thresholds and automatically stop the process
– Clear display for all essential information at a glance
– Integrated timer / counter for the control of kinetic sensitive reactions and reminders
– Viscosities up to 4,000 mPas and volume of up to 5 l
– Continuously adjustable speed between 0/30 – 2,000 rpm
– USB interface, e.g. for documenting parameters using labworldsoft® or installing firmware updates
– Intuitive and simple handling; touch-sensitive surface for long service life
– Temperature reading on display
– Chemically resistant housing
– Key lock function
– Microprocessor-controlled speed governor for constant rotational speed, even with changes in viscosity

Technical data :
– Time setting min. : 0 min
– Hollow shaft, inner diameter : 8.5mm
– Chuck range max. diameter : 8mm
– Temperature measuring range max. : 350°C
– Motor rating input : 32W
– Viscosity max. : 4000mPas
– Motor rating output : 22W
– Speed range I: speed min. (at 60 Hz): 30rpm
– Speed range I: speed min. (at 50 Hz) : 30rpm
– Accuracy of temperature measurement : ±0.5 + tolerance PT1000 (DIN IEC 751 Class A)K
– Time setting max. : 6000min
– Limit deviation temperature sensor : ≤ ± (0.15 + 0.002xITI)K
– Speed min. : 0/30rpm, 30rpm
– Communication distance (depend onbuilding) max. : 150m
– Output max. at stirring shaft : 15.7W
– Torque max. at stirring shaft : 7.5Ncm
– Depth : 136mm
– Width : 60mm
– Height :173mm
– Weight : 1.18kg
– Current consumption : 1300mA
– Power input : 32W
– Torque I max. : 7.5Ncm
– Deviation of torque measurement I : 3±Ncm
– Torque max. at stirring shaft at 100 1/min : 7.5Ncm
– Torque max. at stirring shaft at 60 1/min (overload) : 7.5Ncm
– Torque max. at stirring shaft at 1.000 1/min : 7.5Ncm
– Speed range I: speed max. (at 50 Hz) : 2000rpm
– Nominal torque : 0.075Nm
– Speed range I: speed max. (at 60 Hz) : 2000rpm
– Deviation of speed measurement n > 300rpm : 1±%
– Deviation of speed measurement n < 300rpm : 3±rpm
– Connection for ext. temperature sensor : PT1000
– Temperature display : yes
– Motor principle : Brushless DC
– Housing material : alu-cast coating / thermoplastic polymer
– Torque measurement : trend
– Torque display : yes
– Fastening on stand : extension arm
– Hollow shaft (push-through – when stopped) : yes
– Timer : yes
– Protection class according to DIN EN 60529 : IP 54
– USB interface : yes
– Speed display : LCD
– Stirring element fastening : chuck
– Timer display : LCD
– Speed control : electronic, Turning knob
– Permissible ambient temperature min. : 5°C
– Extension arm diameter : 13mm
– Chuck range min. diameter : 0.5mm
– Extension arm length : 160mm
– Setting accuracy speed : 1±rpm
– Stirring quantity max. per stirring position (H2O) : 5l
– Temperature measurement resolution : 0.1K
– Speed max. : 2000rpm
– Temperature measuring range min. : -10°C
– Permissible relative humidity : 80%
– Permissible ambient temperature max. : 40°C
– Voltage : 100 – 240V
– Frequency : 50/60Hz
– DC Voltage : 24V=
– Permissible ON time : 100%
