Description

RH Digital
Magnetic Stirrers with Heating
Innovatively designed digital magnetic stirrer with heating. Bushing according to DIN 12878 for connecting an electronic contact thermometer, such as the ETS-D5. Highly accurate temperature control is possible with sensor placed directly in the medium. A high heat output of 600 watts and stainless steel compound hot plate ensures rapid heating. Adjustable safety temperature from 100 to 360 °C.
– Digital display of temperature and speed
– Soft-start of stirring motor
– Strong magnetic field and wide speed range for volumes up to 15 liters
– Error code display
– Easy operation with touch keypad

Technical data :
– Heat output : 600W
– Adjustable safety circuit max. : 360°C
– Set-up plate dimensions : Ø 135m
– Stirring quantity max. per stirring position (H2O) : 15l
– Heating temperature min. : 50°C
– Depth : 250mm
– Voltage : 230V
– Stirring bar length max. : 80mm
– Self-heating of the hotplate by max. stirring (RT:22°C/duration:1h) : 28+K
– Stirring bar length min. : 20mm
– Temperature setting range max. : 320°C
– Weight : 2.8kg
– Power input : 620W
– Temperature setting range min. : 50°C
– Adjustable safety circuit min. : 100°C
– Width : 160mm
– Heating rate heating plate : 6K/min
– Height : 100mm
– Heating temperature max. : 320°C
– Direction of rotation : left
– Temperature display set-value : LED
– Temperature unit : °C
– Connection for ext. temperature sensor : ETS-D5
– Set-up plate material : stainless steel 1.4301
– Speed display set-value : LED
– Protection class according to DIN EN 60529 : IP 21
– Heat control : Button
– Speed control : Button
– Frequency : 50/60Hz
– Speed max. : 2000rpm
– Speed min. : 100rpm
– Permissible relative humidity : 80%
– Permissible ambient temperature max. : 40°C
– Motor rating output : 2W
– Permissible ambient temperature min. : 5°C
– Number of stirring positions : 1
