Jual Magnetic Stirrer with Hotplate RCT Basic Ika

Description

RCT basic
Magnetic Stirrers with Heating

The bestseller in laboratories: Strong motor for a higher range of speeds, additional temperature control mode for faster heating of medium
Specifications :
– Integrated temperature control
– Incl. PT 1000 temperature sensor (PT 1000.60)
– Exact temperature and speed setting via digital display, even when switched off
– Set safety temperature limit displayed digitally
– Hot Top indicator >> hot surface warning to prevent burns!
– Digital error code display
– With adjustable safety circuit of heating plate temperature (50 – 360 °C)
– Safety magnetic stirrer with heating, suitable for unsupervised operation
– Bushing according to DIN 12878 for connecting a contact thermometer, e.g. ETS-D5, enables precise temperature control
– High level of safety thanks to improved heat control technology
– Enclosed assembly (IP 42) guarantees long service life
– Aluminium heating plate for optimum heat transfer
– Improved magnetic adhesion
– Incl. protection cover H 100
– Max. stirring quantity (H2O): 20 l
– Speed range: 50 – 1500 rpm
– Temperature range: RT – 310 °C

Technical data :
– Adjustable safety circuit min. : 50°C
– Adjustable safety circuit max. : 360°C
– Set-up plate dimensions : Ø 135mm
– Self-heating of the hotplate by max. stirring (RT:22°C/duration:1h) : 28+K
– Heating temperature min. : Room temp. + device self heating°C
– Heating temperature max. : 310°C
– Speed min. : 50rpm
– Heat output : 600W
– Heating rate heating plate : 6.5K/min
– Stirring bar length min. : 20mm
– Temperature setting range min. : 0°C
– Depth : 270mm
– Height : 85mm
– Weight : 2.5kg
– Power input : 650W
– Width : 160mm
– Setting accuracy speed : 10rp
– Temperature setting range max. : 310°C
– Temperature setting resolution of heating plate : 1K
– Temperature setting resolution of medium : 1K
– Motor rating output : 9W
– Stirring bar length max. : 80mm
– Connection for ext. temperature sensor : PT1000
– Set-up plate material : Aluminium alloy
– Speed display actual-value : LED
– Temperature display set-value : LED
– Heat control : Turning knob
– Protection class according to DIN EN 60529 : IP 42
– Speed control : Turning knob
– Direction of rotation : right
– Speed display set-value : LED
– Temperature display actual-value : LED
– Temperature unit : °C
– Speed max. : 1500rpm
– Stirring quantity max. per stirring position (H2O) : 20l
– Voltage : 220 – 230V
– Frequency : 50/60Hz
– Permissible relative humidity : 80%
– Sensor in medium detection (Error 5) : yes
– Permissible ambient temperature min. : 5°C
– Permissible ambient temperature max. : 40°C
– Number of stirring positions : 1
