Description

LR-2.ST the High-Performer
Modularly configured laboratory reactor for the optimization and reproduction of various chemical reactions, mixing and homogenization processes on a lab scale.
The system is particularly characterized by the agitator mounting, which allows for a safe transfer of the higher motor torque.
ULTRA-TURRAX® dispersers, temperature sensors, flow breakers and other accessories can be attached to the open ports of the reactor cover.

– Suitable for vacuum operation
– Solvent- and temperature-resistant perfluoroelastomer (FFPM) seals come into contact with sample
– Infinitely variable speed
– Torque trend display for measuring changes in viscosity
– Microprocessor-controlled speed regulation, enables steady speed, also under load
– Removable WiCo (wiresless controller) for remote and safe use in a fume hood

The LR-2.ST laboratory reactor system consists of :
– Stand system
– EUROSTAR 200 control P4 laboratory stirrer with higher torque
– Safety
– Reactor cover

Technical data :
Usable volume min. : 500ml
Usable volume max. : 2000ml
Working temperature max. : 230°C
Telescope stand stroke : 390mm
Width : 460mm
Weight : 25kg
Height : 1240mm
Depth : 430mm
Working temperature min. : Room temp.°C
Viscosity max. : 150000mPas
Permissible ambient temperature max. : 40°C
Permissible ambient temperature min. : 5°C
Reactor vessel openings (units/standard) : 3/NS 29/32 2/NS 14/23
Permissible relative humidity : 80%
Attainable vacuum : 25mbar
Speed min. : 8rpm
Speed max. : 290rpm
Material in contact with medium : borosilicate glass, FFPM, PTFE, steel 1.4571
