Deskripsi
Jual GENESYS 150 UV-Visible Spectrophotometer
Jual Alat Laboratorium Umum
Produk lain : https://distributorflowmeters.com/ |
Jual GENESYS 150 UV-Visible Spectrophotometer
Spesifikasi GENESYS 150 UV-Visible Spectrophotometer
Specifications:
| Baseline Flatness | ± 0.002 A | |
| Compartments | Accommodates optional accessories
8-position cell changer 4-position cell changer (long path cells) Peltier thermostatted cell holder (20 °C – 60 °C) Sipper accessory Fiber optic probe coupler |
|
| Connections | Single USB-A supports flash memory devices for method and data storage
Duplex USB-A on side supports connection to a Windows™ computer running optional remote control software, keyboard, and mouse; Export data to network or PC via USB, Ethernet, or Wi-Fi |
|
| Description | GENESYS™ 150 UV/Visible Spectrophotometer | |
| Detector Type | Dual Silicon Photodiodes | |
| Dimensions,
(L x W x H) |
35.5 x 38.5 x 19.5 cm | |
| Display | 7-inch color touchscreen, tiltable, high definition, 800 x 1280 pixels | |
| Drift | < 0.0010 A/Hr (At 500 nm after 1 hour warmup) | |
| Keypad | Touchscreen | |
| Lamp | Xenon Flash Lamp (> 5 years typical, 3 years guaranteed) | |
| Noise | (RMS at 500 nm 60 consecutive measurements)
</= 0.00020 A @ 0 A @ 260 and 500 nm </= 0.00030 A @ 1 A @ 260 and 500 nm </= 0.00040 A @ 2 A @ 260 and 500 nm |
|
| Optical Design | Dual beam | |
| Photometric | Instrument
Accuracy |
± 0.002 A @ 0.5 A
± 0.004 A @ 1.0 A ± 0.008 A @ 2.0 A |
| Display | – 3 A to + 5 A | |
| Range | – 2 A to + 3.5 A | |
| Repeatability | ± 0.001 A @ 1 A (measured at 1.0 A at 546 nm) | |
| Power Requirements | External AC to DC converter, Voltage and Frequency (Hz) are selected automatically, 100 to 240 V, 50 to 60 Hz | |
| Printer | Snap-on printer (optional—purchase separately) | |
| Resolution | 0.2 nm. 0.5 nm, 1 nm, 2 nm, 5 nm | |
| Spectral Bandwidth | 5 nm | |
| Stray Light | < 1.0% T @ 198 nm (KCL)
< 0.05 % T @ 220 nm (Nal) < 0.03 %T @ 340 nm (NaNO2) |
|
| Wavelength | Accuracy | ± 0.5 nm |
| Range | 190 nm to 1100 nm | |
| Repeatability | < ± 0.2 nm | |
| Scan Speed | Slow, medium, and fast — up to 1600 nm/min | |
| Weight | 7.5 kg | |
